| AC Voltage Regulation (Batt.Mode): | |
|---|---|
| Surge power: | |
| Wave form: | |
| Battery Voltage: | |
| MAX.PV Array Power: | |
| Quantity: | |
BT-SIVT
Bestop
054789987
The inverter is a converter that converts direct current energy (battery, battery) into fixed frequency and voltage or frequency and voltage regulation alternating current (generally 220V,50Hz sine wave). It consists of inverter bridge, control logic and filter circuit. Widely used in air conditioning, home theater, electric grinding wheel, power tools, sewing machine, DVD, VCD, computer, TV, washing machine, range hood, refrigerator, video recorder, massager, fan, lighting and so on. If driving to work or travel, the inverter can be connected to the battery to drive electrical appliances and various tools. The on-board inverter output through the cigarette lighter is 20W, 40W, 80W, 120W to 150W power specifications. More power inverter power is connected to the battery through the connection line. By connecting household appliances to the output of the power converter, various appliances can be used in the car. Electrical appliances that can be used are: mobile phones, laptops, digital cameras, cameras, lighting, electric shavers, CD players, game consoles, handheld computers, power tools, car refrigerators and all kinds of travel, camping, medical emergency appliances.
The inverter not only has the function of direct AC conversion, but also has the function of maximising the function of solar cell and the function of system fault maintenance. In summary, there are active operation and shutdown function, maximum power tracking and throttling function, anti-alone operation function (for grid-connected system), active voltage adjustment function (for grid-connected system), DC detection function (for grid-connected system), DC grounding detection function (for grid-connected system).
| Models | ISolar-SMH-II-2.2KW | ISolar-SMH-II-3.2KW |
| Rated Power | 2200VA/1800W | 3200VA/3000W |
| INPUT | ||
| Voltage | 230Vac | |
| Selectable Voltage Range | (170Vac~280Vac) ±2%；(90Vac-280Vac)±2% | |
| Frequency Range | 50Hz/ 60Hz (Auto detection) | |
| OUTPUT | ||
| AC Voltage Regulation (Batt.Mode) | 230VAC±5% | |
| Surge power | 4400VA | 6400VA |
| Transfer Time | 10ms (for personal computers) / 20ms (for home appliances) | |
| Wave form | Pure Sine Wave | |
| BATTERY & AC CHARGER | ||
| Battery Voltage | 12VDC | 24VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC |
| Overcharge Protection | 15.5VDC | 31VDC |
| Maximum charge current | 60A | |
| SOLAR CHARGER | ||
| MAX.PV Array Power | 2000W | 3000W |
| MPPT Range@ Operating Voltage | 55-450VDC | |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum Charging Current | 80A | |
| Maximum Efficiency | 98% | |
| PHYSICAL | ||
| Dimension.D*W*H(mm) | 405x286x98mm | |
| Net Weight (kgs) | 4.5kg | 5.0kg |
| Communication Interface | RS232/RS485(Standard) / GPRS/WIFI(Optional) | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Operating Temperature | -10°C to 55°C | |
| Storage Temperature | -15°C to 60°C | |
1. who are we?
We are based in Shandong, China, start from 2005
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Energy Storage System,,Solar Controller,Grid Tie Inverter
5. what services can we provide?
Accepted Delivery Terms: FOB,EXW CIF
